Description
The 900mm shelf support bar is designed to reinforce MDF and particleboard shelves in standard Longspan bays.
Installed between beams, these front-to-back bars distribute weight more evenly and improve shelf performance, especially under medium to heavy loads.
Why use a shelf support bar?
✅ Improves UDL capacity by supporting the centre of the shelf
✅ Reduces bowing and deflection – even under full load
✅ Simple to install – Sits in place between Beams
✅ Essential for 900 – 1200mm shelf depths using timber panels
🔧 Product Specifications
| Attribute | Details |
|---|---|
| Nominal Length | 900mm shelf depth |
| Actual Length | 810mm (OA – Over All) |
| Material | 1.5mm thick pre-galvanised steel |
| Components | 1 x bracing bar + 2 x cleats (fitted on-site) |
| Use | Sits front-to-back between beams, under the shelf |
| Recommended Quantity | 2 per shelf (minimum) |
🛠️ Installation Notes
-
Use at least 2 bars per shelf (never one alone).
-
For wider or heavier-loaded shelves, 3 bars is recommended.
-
Ensure bars are spaced symmetrically to avoid point loading.
